    GM150 Miniature Sensor

    Ask Lasest Price
    Brand Name : QingCheng AE
    Model Number : GM150 Miniature Sensor
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 100 pcs per month
    Delivery Time : 7-30 days
    • Product Details
    • Company Profile

    GM150 Miniature Sensor


    Applications


    GM150 is a passive piezoelectric miniature AE sensor, it can be used for monitoring common structures


    such as pipelines, vessels, bridges, storage tanks etc. It can easily mounted in small and tight space.


    Technical Specs
    Resonant Freq. Ref V/(m/s)150kHz
    Frequency Range70kHz-280kHz
    Sensitivity Peak Ref V/(m/s)>68dB
    Working Temp.-20 to 120℃
    Size(DxH)7.9×19mm
    Weight5g
    Case MaterialSUS-304
    Face MaterialCeramic
    Protecting GradeIP62
    ConnectorM5
    Connector LocationTop
    Accessories
    Signal cable modelRG178/RG316
    Hold-downSaddle type
    PreamplifierPAS/PAV


    Further Information



    • Company information

    Shanghai Liangui Technology Co., Ltd. is committed to promoting the prosperity and development of the world through technology, focusing on Intelligent Equipment & Automation Solutions to to help enterprises to improve production process and minimize the cost.


    We are an intelligent equipment & automation solution integration service provider. Our company has a professional foreign trade sales team and an experienced technical support team, the principles of our team work is customer first and fast solution. Our business scope includes NDT Testing Equipment, Acoustic Emission Testing Instruments, Industrial Robot, Mechanical and Electrical Equipment etc.


    Our NDT testing division is specialized in the R & D, production, sales and technical application services of Acoustic Emission Testing Instruments, Ultrasonic Flaw Detector, Ultrasonic Thickness Gauge and other Testing Instruments. Our R&D team has the ability to develop Sensors, Electronic Measurement Software and Hardware, we can also customize Non-standard Automated and Robotic Inspection Equipment for customers. Our products mainly used in Industrial Field (Aerospace, Railway, Automotive, Oil & Gas, Manufacturing, Process Industry ) and Power Generation (Renewable, Nuclear, New Reactors, Advanced Reactors, Research Reactors, Gas Combined, Coal, Cogeneration).


    Our objective is to always help our clients meet their high safety standards, proposing efficient inspection solutions based on global services which reduce costs and increase process efficiency, make industrial facilities and power generation to operate safely, efficiently and excellently. Our major products AE system and instruments have been sold to China, USA, UK, Brazil, Indonesia and so on, which win the trust and support of customers from all over the world with an excellent reputation.


    • Paramaeter table
    Sensor model naming rules: the first letter marks narrowband G or wideband W. The middle number is the center frequency KHz, after the number/marks the subdivision model, and the specific difference is indicated in the remarks column. Other female definitions: built-in front amplifier (I), high temperature (H), intrinsically safe explosion-proof (S), differential (D), miniature (M).
    Model New / OldResonant frequencyFrequency rangePeak sensitivityBuilt-in frontSize. mmProduct feature
    G150 SR150M 150KHz 60KHz~400KHz ﹥75dB / Φ19×15 Narrow-band
    G40 SR40M 40KHz 15KHz~70KHz ﹥75dB / Φ22×36.8 Narrow-band
    G80 G8 80KHz 20KHz~180KHz ﹥70dB / Φ19×19.5 Narrow-band
    G10 SR10B 10KHz 1Hz-15kHz >80dB / Φ31×38 Ultralow frequency
    G10/1 SR10C 10KHz 1Hz-15kHz >80dB / Φ31×38 Narrow-band
    GI150 SRI150 150KHz 60KHz~400KHz ﹥75dB 40dB28V Φ30×36.5 Built-in front
    GI150/1 PG15 150KHz 60KHz~400KHz ﹥75dB 40dB28V Φ22×25.5 Built-in front
    GI150/2 LG15 150KHz 60KHz~400KHz >75dB 26dB5V Φ22×25.5 Built-in front
    GI150/3 / 150KHz 60KHz~400KHz >75dB 34dB12V Φ22×25.5 Built-in front
    GI150/4 / 150KHz 60KHz~400KHz >75dB 40dB28V Φ30×35 Built-in front
    GI40 SRI40 40KHz 15KHz~70KHz ﹥75dB 40dB28V Φ30×57 Built-in front
    GI35 PG3 40KHz 15KHz~70KHz ﹥75dB 40dB28V Φ22×42.6 Built-in front integration
    GI35/1 LG3 40KHz 15KHz~70KHz >75dB 26dB5V Φ22×42.6 Built-in front integration
    GI35/2 / 40KHz 15KHz~70KHz >75dB 34dB12V Φ22×42.6 Built-in front integration
    GM150 SR150S 150kHz 70kHz-280kHz >68dB / Φ7.8×19 Narrow-band minitype
    GM150/1 / 150kHz 70kHz-280kHz >68dB / Φ7.8×14 Narrow-band minitype
    G150/1 CG15 150KHz 60KHz~400KHz ﹥75dB / Φ19×15 Waterproof
    G150/2 XG15 150KHz 60KHz~400KHz >70dB / Φ19×19.5 Waterproof metal
    GI40/2 BF40 50KHz 15KHz~70KHz ﹥75dB 40dB28V Φ41×92 Embedded narrow-band integration
    GD150 DG15 150KHz 60KHz~400KHz ﹥65dB / Φ19×19.5 Difference waterproof
    GD40 DG4 35KHz 15KHz~70KHz >65dB / Φ22×25 Difference waterproof
    GI10 BE10 10KHz 1Hz-15kHz ﹥80dB 26dB5V Φ38.5×85 Low frequency built-in front
    GI10/1 / 10KHz 1Hz~15kHz >80dB 34dB12V Φ38.5×85 Low frequency built-in front
    GSI150 / 150KHz 60KHz~400KHz >73dB /

    (Φ21.7×25 amplifier)

    Φ19×14 sensor

    Intrinsic safety

    anti-explosion

    GIS35 / 40KHz 15KHz~70KHz >75dB 26dB5V Φ22×42.6

    Intrinsic safety

    anti-explosion

    LS  5VDC(A款) / 35KHz 15KHz~70KHz >65dB 26dB5V Φ22×36.8

    Intrinsic safety

    anti-explosion

    LS  5VDC(B款) / 150KHz 60KHz~400KHz >75dB 26dB5V Φ22×25.5

    Intrinsic safety

    anti-explosion

    GH150 HG15c 150KHz 60KHz~400KHz >60dB / Φ19×19.5 Ultra-high temperature narrow band
    GH150/1 / 150KHz 60KHz~400KHz >73dB / Φ19×19.5 High temperature narrow band
    GH150/2 / 150KHz 60KHz~400KHz >73dB / Φ19×15 Medium-high temperature narrow band
    W500 WG50 500KHz 100KHz-1000kHz >65dB / Φ19×15 Broadband
    W800 SR800 600KHz 50KHz~800KHz >65dB / Φ19×15 Broadband
    WI500 / 500KHz 100KHz~1000kHz >65dB 40dB28V Φ22×25.5 Forward integration
    WI500/1 / 500KHz 100KHz-1000kHz >65dB 34dB12V Φ22×25.5 Broadband forward integration
    W500/1 CG50 500KHz 100KHz-1000kHz >65dB / Φ19×15 Broadband waterproof
    W800/1 CG80 600KHz 50KHz~800KHz >65dB / Φ19×15 Broadband waterproof
    WM500/1 MG50 500KHz 100KHz-1000kHz >65dB / Φ4.7×4.0 Broadband minitype

    • FAQ

    1.What is the trade type of your company?

    Manufacture and trading.

    2.What is your delivery time?

    10-30 days according to different order quantity.

    3.What is your warranty time?

    One year after delivery date.

    4.Whether OEM/ODM is avaliable?

    Yes.
